APT port FTTH fiber termination box is wall mountable and rack mountable and can be used for exterior walls, basements, and other locations needing FTTH. The box is UV and weather resistant and can be used with a variety of adapters with a SC footprint.

Introduction

1.Description

APT 8 port FTTH fiber termination box is wall mountable and rack mountable and can be used for exterior walls, basements, and other locations needing FTTH. The box is UV and weather resistant and can be used with a variety of adapters with a SC footprint.

2.Features

1)Wall mountable

2)UV Resistant

3)Weather Resistant

4)The base and cover of the box adopts a "self-clip" method, which is easy and convenient to open and close

5)Can be used with SC simplex adapters or LC duplex adapters with a SC footprint

6)The max capacity is 8 fibers

7) Cable, pigtails, patch cords are running through own path without disturbing each other, cassette type SC adapter installation, easy maintenance

8) Distribution panel can be flipped up, feeder cable can be placed in a cup-joint way, easy for maintenance and installation.

3.Specification

Environmental requirement

Working Temperature:-40℃~+85℃

Relative humidity:≤85%(+30℃)

Atmospheric pressure:70Kpa~106Kpa

Main technical datasheet

Insertion loss:≤0.2dB

UPC return loss:≥50dB

APC return loss:≥60dB

Life of insertion and extraction:>1000 times

Size

235*125*50mm
